Space-saving staircase Quatro Turn

Quatro Turn

  • Special version of Quatro with a platform for a 90-degree turn
  • Platform can be installed flexibly between first and last step
  • High-quality lacquered wood in beech or beech stained to walnut
  • Powder-coated metal parts in black, grey or white
  • Handrail made of lacquered wood
  • Maximum storey height: 2980 mm

Hier soll der Validierungstext stehen.Die Treppe ist für diese Raumhöhe geeignet.

 1,550.40 incl. Tax excl. Shipping Costs*

Description

The Quatro Turn is a special version of the Quatro space-saving staircase. This model comes with a platform that allows the staircase to be assembled with a 90-degree turn. This means that it can be adapted to a wide range of architectural circumstances so that you can always get to the top and back down again.

Flexible design.

Thanks to the flexible technology of the Minka staircases, you have a wide range of options when setting up the Quatro Turn: The platform can be installed entirely according to your wishes from the first to the last step. The striking metal parts of the Quatro Turn are available in black, grey and white. In addition, you can choose the steps and the handrail in either a light beech wood or a darker walnut look.

Sustainable use.

Thanks to the high-quality lacquer finish, the steps of the Quatro Turn are well protected against scratches and abrasion. The metal parts of the staircase are surface-finished with Minka powder coating and therefore also score with high durability. This means that you can enjoy your new staircase for a long time, which is not only good for you, but also for the environment.

Technical data

Basic data
Steps Beech lacquered or beech stained to walnut
Handrail Beech lacquered or beech stained to walnut
Metal parts Steel powder-coated in grey, black or white
Bottom chords Stainless Steel
Dimensions Quatro Turn
Max. storey height 2980 mm
Max. storey height with one height extension 3210 mm
Tread depth 210 mm
Rise per step 190 - 230 mm
Free passage width 600 mm
Tread thickness 35 mm
Railing height 900 mm
Railing rod diameter 22 mm
Handrail diameter 40 mm
Number of steps 12 + 1 platform
