Rondo Zink Smart
- Galvanised spiral staircase for outdoor use
- Studded steps provide a secure grip when climbing the stairs
- Railing with galvanised metal rods and handrail made of high-quality PVC
- Four diameters: 120, 140, 160 or 180 cm
- Maximum storey height: 3055 mm
€ 2,612.40 – € 3,422.40 incl. Tax excl. Shipping Costs*
-
Description
With the galvanised spiral staircase Rondo Zink Smart, you can easily reach terraces, balconies or raised entrance doors outside. This model is also perfectly suitable as an emergency staircase. However, the Rondo Zink Smart is not only practical, but also a visual eye-catcher. For example, it can also be used indoors to create a unique and modern industrial interior look.
Flexible design.
The outdoor staircase Rondo Zink Smart is available in three different sizes. Depending on the space available, you can choose between a diameter of 120, 140, 160 or 180 cm. The height of the spindle elements can be adjusted, allowing you to adapt the overall height of the staircase exactly to your situation. Without height extensions, you can achieve a maximum storey height of 3055 mm with the Rondo Zink Smart.
Sustainable use.
The steel steps, the spindle elements and the railing of the Rondo Zink Smart are made of hot-dip galvanised steel. This makes them resistant to corrosion, wear and various other environmental influences. The handrail is made of a high-quality PVC that is not only weatherproof but also very comfortable to hold.
-
Technical data
Basic dataSteps Steel galvanisedSpindle tubes Steel galvanisedRailing rods Steel galvanisedHandrail PVC greyNumber of steps 12 + 1 platform120Radius 600 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 196 mmFree passage width 486 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 29,6°Platform width 650 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm140Radius 700 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 213 mmFree passage width 586 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 25°Platform width 750 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm160Radius 800 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 223 mmFree passage width 686 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 21,9°Platform width 850 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm180Radius 900 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 233 mmFree passage width 786 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 19,4°Platform width 950 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm -
Downloads
Matching products
-
Height extension for Rondo Zink Smart
€ 333.60 incl. Tax excl. Shipping Costs*incl. VAT
plus Shipping Costs
Delivery time: 5-10 working days
Select options -
Balustrade for Rondo Zink Smart
€ 213.60 incl. Tax excl. Shipping Costs*incl. VAT
plus Shipping Costs
Delivery time: 5-10 working days
Add to cart
Reviews
There are no reviews yet.
