Height extension for Rondo Zink Smart
- Additional step for spiral staircase Rondo Zink Smart
- Extension of Rondo Zink Smart by 190-235 mm
- Maximum attainable storey height with one height extension: 3290 mm
- Maximum attainable storey height with two height extensions: 3525 mm
- When purchasing, please ensure that the height extension has the same configuration as your staircase and install a maximum of two height extensions per staircase.
€ 333.60 incl. Tax excl. Shipping Costs*
-
Description
If the outdoor staircase Rondo Zink Plus is not high enough for your building project, you can extend it a little with a height extension. This consists of an additional step, a spindle element, railing rods and various small parts for assembly. When ordering, please ensure that the diameter of your staircase and the height extension are the same.
With the supplied additional step including spindle tube, you can extend the Rondo Zink Smart by 190-235 mm. With one height extension, you can thus achieve a maximum storey height of 3290 mm. With two additional steps installed, you can even climb storeys with a height of up to 3525 mm.
Please install a maximum of two height extensions per staircase! If three or more additional steps are installed, stability is no longer guaranteed.
-
Technical data
Basic dataSteps Steel galvanisedSpindle tubes Steel galvanisedRailing rods Steel galvanisedHandrail PVC greyNumber of steps 12 + 1 platform120Radius 600 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 196 mmFree passage width 486 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 29,6°Platform width 650 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm140Radius 700 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 213 mmFree passage width 586 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 25°Platform width 750 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm160Radius 800 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 223 mmFree passage width 686 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 21,9°Platform width 850 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm180Radius 900 mmMax. storey height 3055 mmMax. storey height with one height extension 3290 mmMax. storey height with two height extensions 3525 mmTread depth 233 mmFree passage width 786 mmTread thickness 4 mmRise per step 190-235 mmRotation per step 19,4°Platform width 950 mmRotation of platform 54°Spindle diameter 108 mmRailing height 1000 mmHandrail diameter 40 mm -
